R32 Refrigerant VRF System Ultra-Low Standby 3.5W

Product Description

The V8 Mini series is Midea's compact solution designed specifically for small commercial and residential VRF applications. With capacities ranging from 8-18kW (single-phase 220-240V) or 12-18kW (three-phase 380-415V), the V8 Mini offers the perfect balance of performance and compact footprint for installations where space is at a premium.

Featuring eco-friendly R32 refrigerant with a Global Warming Potential (GWP) of just 675, the V8 Mini series delivers significantly lower environmental impact compared to R410A systems while maintaining excellent performance. The innovative M-Holmes R32 safety technology provides comprehensive protection including refrigerant cutoff devices, alarm systems, and leak detection sensors for safe operation in occupied spaces.

Despite its compact size, the V8 Mini series incorporates Midea's advanced VRF technologies including SuperSense 13-sensor monitoring, META 2.0 intelligent control, and Full DC Inverter technology. The 15°C supercooling technology extends piping capacity, while the ultra-low 3.5W standby power consumption ensures energy efficiency even when the system is not actively cooling or heating.

With a 50%-160% combination ratio and HyperLink communication supporting up to 2000 meters, the V8 Mini series is ideal for small retail shops, apartments, home offices, and projects looking to replace traditional split systems with more efficient VRF technology. Note: V8 Mini series indoor units must be installed at a minimum height of 1.8m and are only compatible with V8 indoor units.

Features & Benefits

R32 Eco-Friendly Refrigerant — Low GWP of 675 with zero ozone depletion potential for reduced environmental impact

M-Holmes R32 Safety Technology — Advanced safety system with refrigerant cutoff, alarm, and leak detection

SuperSense Technology — 13-sensor monitoring system for precise performance optimization

META 2.0 Control Algorithm — Intelligent three-variable optimization achieving 28%+ energy savings

Full DC Inverter Technology — Maximum energy efficiency with precise temperature control

15°C Supercooling — Extended piping capacity for flexible installation options

HyperLink 2000m — Communication distance up to 2000 meters for versatile positioning

Ultra-Low Standby Power — 3.5W standby consumption for energy efficiency

Compact Design — Space-saving form factor ideal for limited installation areas

Single & Three-Phase Options — Flexible power configuration for various electrical systems

Applicable Scenarios

The V8 Mini series is engineered for compact applications requiring eco-friendly VRF performance:

Small Retail Shops — Boutiques, convenience stores, and small restaurants with limited space

Residential Apartments — Individual units and small residential buildings seeking VRF efficiency

Home Offices — Dedicated workspaces requiring reliable climate control

Traditional Split System Replacements — Upgrading from aging split systems to modern VRF technology

Compact Commercial Spaces — Small clinics, beauty salons, and service businesses

Balcony Installations — Where traditional outdoor unit placement is not possible

R32 Environmental Benefits

Low Global Warming Potential — GWP of 675 - significantly lower than R410A (2088)

Zero Ozone Depletion — Zero ODP contributing to environmental protection

Lower Charge Requirements — R32 requires less refrigerant volume for equivalent capacity

High Energy Efficiency — Excellent thermodynamic properties for superior system efficiency

Certifications & Standards

Eurovent Certified Performance — Verified efficiency and capacity data

ERP Energy Efficiency — Compliant with EU energy performance regulations

RoHS Compliant — Meeting environmental safety standards

Technical Data
