V8 Series VRF System Cost-Effective Solution 8-108HP Value Optimized

Product Details

Place of Origin: China

Brand Name: Midea

Certification: CB, ISO

Payment & Shipping Terms

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                V8 Series VRF system cost-effective, DC inverter VRF system 8-108HP, VRF system value optimized warranty


Product Name:	V8 Eco VRF System	Capacity Range:	8-108HP (Combinable)
Cooling Capacity:	25.2 - 90 KW (Individual Unit)	Heating Capacity:	27.0 - 100 KW (Individual Unit)
SEER:	5.80 - 7.55	SCOP:	4.25 - 4.48
Refrigerant:	R410A	Power Supply:	380-415V / 3Ph / 50Hz
Combination Ratio:	50%-150% (up To 200% Under Specific Conditions)

Product Name:	V8 Eco VRF System
Capacity Range:	8-108HP (Combinable)
Cooling Capacity:	25.2 - 90 KW (Individual Unit)
Heating Capacity:	27.0 - 100 KW (Individual Unit)
SEER:	5.80 - 7.55
SCOP:	4.25 - 4.48
Refrigerant:	R410A
Power Supply:	380-415V / 3Ph / 50Hz
Combination Ratio:	50%-150% (up To 200% Under Specific Conditions)

V8 Series VRF System Cost-Effective Solution 8-108HP Value Optimized

V8 Series VRF System - Cost-Effective Solution 8-108HP Value Optimized

The V8 series VRF System is the cost-optimized solution in the 8th generation VRF lineup, designed to deliver reliable performance and energy efficiency at an accessible price point. With capacities ranging from 8 to 108HP, the V8 series is perfectly suited for small to medium commercial projects, residential complexes, and renovation applications where budget considerations are paramount.

Despite its cost-effective positioning, the V8 series does not compromise on essential features. It incorporates core technologies including SuperSense, META 2.0, and ShieldBox protection, ensuring the same high standards of reliability that VRF systems are known for worldwide.

Features & Benefits

SuperSense System

19 sensors provide comprehensive monitoring of the refrigerant system, ensuring stable operation and enabling accurate refrigerant volume diagnosis.

META 2.0 Technology

Intelligent triple-variable control delivers 28%+ energy savings by optimizing refrigerant temperature, indoor airflow, and flow rate based on actual load.

ShieldBox Protection

IP55-rated electrical enclosure protects components from dust, humidity, and corrosion for reliable outdoor installation.

EVI Compressor

Enhanced vapor injection technology extends heating capability to -30°C while improving overall system efficiency.

Full DC Inverter

DC inverter compressors and fan motors ensure precise capacity control and excellent energy efficiency.

Triple Backup Protection

Compressor backup, fan backup, and virtual sensor backup provide reliable operation continuity.

Flexible Combination Ratio

50%-150% connection ratio (expandable to 200%) accommodates a wide range of project configurations.

Economical Design

Streamlined features provide essential VRF performance without unnecessary complexity, maximizing value for budget-conscious projects.

Applications

Small to Medium Commercial - Retail shops, small offices, and local businesses

Residential Complexes - Apartment buildings, condominiums, and housing developments

Renovation Projects - Upgrading from older split systems or window units

Budget-Sensitive Projects - Cost-effective VRF solutions for price-conscious clients

Education - Schools and training facilities with moderate cooling/heating needs

Certifications & Standards

Eurovent Certified

UL Anti-Corrosion (Optional)

ERP Compliant

RoHS Compliant

ISO 9001

Technical Specifications

Parameter	Specification
Capacity Range	8-108HP (Combinable)
Cooling Capacity	25.2 - 90 kW (Individual Unit)
Heating Capacity	27.0 - 100 kW (Individual Unit)
SEER	5.80 - 7.55
SCOP	4.25 - 4.48
Refrigerant	R410A
Power Supply	380-415V / 3Ph / 50Hz
Cooling Operation	-15°C to 55°C
Heating Operation	-30°C to 30°C
Combination Ratio	50%-150% (up to 200% under specific conditions)
Communication Distance	Up to 1200m
External Static Pressure	0-80Pa
