V8 Series VRF System Premium Flagship 8-96HP Eurovent Certified

Product Details

Place of Origin: China

Brand Name: Midea

Certification: CB, ISO

Payment & Shipping Terms

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                DC Inverter VRF system with warranty, V8 Series VRF Eurovent certified, Premium VRF system 8-96HP


Product Name:	V8 Master VRF System	Capacity Range:	8-96HP (Combinable) \| 8-32HP (Individual)
Cooling Capacity:	25.2 - 90 KW (Individual Unit)	Heating Capacity:	27.0 - 100 KW (Individual Unit)
SEER:	5.80 - 7.55	SCOP:	4.25 - 4.48
Refrigerant:	R410A	Power Supply:	380-415V / 3Ph / 50Hz
Max Connected Indoor Units:	53 Units

Product Name:	V8 Master VRF System
Capacity Range:	8-96HP (Combinable) \| 8-32HP (Individual)
Cooling Capacity:	25.2 - 90 KW (Individual Unit)
Heating Capacity:	27.0 - 100 KW (Individual Unit)
SEER:	5.80 - 7.55
SCOP:	4.25 - 4.48
Refrigerant:	R410A
Power Supply:	380-415V / 3Ph / 50Hz
Max Connected Indoor Units:	53 Units

V8 Series VRF System Premium Flagship 8-96HP Eurovent Certified

Product Overview

The V8 series VRF System represents the pinnacle of Variable Refrigerant Flow technology, designed for large-scale commercial and residential applications. As the flagship model in the 8th generation VRF lineup, the V8 Master delivers exceptional performance with capacities ranging from 8 to 96HP, making it ideal for office complexes, hotels, hospitals, and large residential developments.

Advanced Technology Features

SuperSense System – Up to 19 sensors monitor every aspect of the refrigerant system, providing real-time status visibility and virtual sensor backup for uninterrupted operation.
META 2.0 Technology – Proprietary triple-variable control technology that automatically adjusts refrigerant temperature, indoor airflow, and refrigerant flow based on actual load conditions, achieving 28%+ annual energy savings.
ShieldBox IP55 Protection – Fully-enclosed electrical control box protects electronic components from corrosion, dust, humidity, and insects, ensuring reliability in harsh environments.
EVI Compressor Technology – Enhanced Vapor Injection compressor increases refrigerant circulation, improving both cooling and heating capacity while enabling operation at temperatures as low as -30°C.
60-Step Energy Management – Precise capacity output adjustment from 40% to 100% in 1% increments, providing exceptional flexibility for varying load conditions.
Quadruple Backup Protection – Unit backup, compressor backup, fan backup, and virtual sensor backup ensure continuous operation even when component failures occur.
HyperLink Communication – Supports any wiring topology (star, tree, ring) with communication distance up to 2000m, simplifying installation and reducing costs.
Low Standby Power – Intelligent standby mode reduces power consumption to as low as 3.5W when no cooling or heating demand is detected.

Recommended Applications

Large Commercial Complexes – Shopping malls, office buildings, and mixed-use developments
Hospitality – Hotels, resorts, and conference centers requiring year-round comfort
Healthcare – Hospitals, clinics, and medical facilities with critical climate requirements
Education – Universities, schools, and libraries with large cooling/heating loads
High-End Residential – Luxury apartments and residential complexes

Certifications & Standards

Eurovent Certified • UL Anti-Corrosion (27 years salt spray resistance) • ERP Compliant • RoHS Compliant • ISO 9001

Technical Specifications

Parameter	Specification
Capacity Range	8-96HP (Combinable) \| 8-32HP (Individual)
Cooling Capacity	25.2 - 90 kW (Individual Unit)
Heating Capacity	27.0 - 100 kW (Individual Unit)
SEER	5.80 - 7.55
SCOP	4.25 - 4.48
Refrigerant	R410A
Power Supply	380-415V / 3Ph / 50Hz
Cooling Operation	-15°C to 55°C
Heating Operation	-30°C to 30°C
Max Connected Indoor Units	53 units
Pipe Length	Up to 1100m total
Height Difference	110m (ODU above/below IDU)
