V8 Series VRF System Professional Series 8-108HP High Efficiency

Product Details

Place of Origin: China

Brand Name: Midea

Certification: CB, ISO

Payment & Shipping Terms

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                V8 Series VRF system high efficiency, DC inverter VRF system 8-108HP, Professional VRF system with warranty


Product Name:	V8 Pro VRF System	Capacity Range:	8-108HP (Combinable) \| 8-36HP (Individual)
Cooling Capacity:	25.2 - 90 KW (Individual Unit)	Heating Capacity:	27.0 - 100 KW (Individual Unit)
SEER:	5.80 - 7.55	SCOP:	4.25 - 4.48
Refrigerant:	R410A	Power Supply:	380-415V / 3Ph / 50Hz
Max Connected Indoor Units:	64 Units	Combination Ratio:	50%-130% (up To 200% Under Specific Conditions)

Product Name:	V8 Pro VRF System
Capacity Range:	8-108HP (Combinable) \| 8-36HP (Individual)
Cooling Capacity:	25.2 - 90 KW (Individual Unit)
Heating Capacity:	27.0 - 100 KW (Individual Unit)
SEER:	5.80 - 7.55
SCOP:	4.25 - 4.48
Refrigerant:	R410A
Power Supply:	380-415V / 3Ph / 50Hz
Max Connected Indoor Units:	64 Units
Combination Ratio:	50%-130% (up To 200% Under Specific Conditions)

V8 Series VRF System Professional Series 8-108HP High Efficiency

Product Overview

The V8 series VRF System represents the cost-optimized solution within the 8th generation VRF lineup, delivering an exceptional balance of performance, reliability, and cost-effectiveness. With capacities ranging from 8 to 108HP, this series serves diverse commercial applications including office buildings, retail spaces, educational institutions, and healthcare facilities.

Advanced Technology Features

SuperSense System: 19 precision sensors continuously monitor refrigerant system status, enabling predictive maintenance and ensuring optimal performance
META 2.0 Technology: Triple-variable control optimizes refrigerant temperature, indoor airflow, and flow rate for 28%+ energy savings
ShieldBox IP55 Protection: Robust enclosure protects electrical components from environmental factors including salt air, dust, and humidity
EVI Compressor Technology: Enhanced vapor injection extends heating operation capability down to -30°C ambient temperature
Full DC Inverter Technology: Both compressor and fan motors utilize DC inverter technology for precise speed control and improved efficiency
Duty Cycling: Equalizes running time across multiple compressors and outdoor units, significantly extending equipment lifespan
60-Step Energy Management: Fine-tune capacity output from 40% to 100% in 1% increments for maximum flexibility
Extended Operating Range: Stable cooling operation from -15°C to 55°C and heating from -30°C to 30°C

Applications

Commercial Buildings: Office complexes, administrative centers, and business parks
Retail Spaces: Shopping malls, retail stores, and entertainment venues
Educational Facilities: Schools, universities, and training centers
Healthcare: Medical clinics, pharmacies, and healthcare offices
Hospitality: Hotels, restaurants, and hospitality venues

Certifications & Standards

Eurovent Certified • UL Anti-Corrosion (Optional) • ERP Compliant • RoHS Compliant • ISO 9001

Technical Specifications

Parameter	Specification
Capacity Range	8-108HP (Combinable) \| 8-36HP (Individual)
Cooling Capacity	25.2 - 90 kW (Individual Unit)
Heating Capacity	27.0 - 100 kW (Individual Unit)
SEER	5.80 - 7.55
SCOP	4.25 - 4.48
Refrigerant	R410A
Power Supply	380-415V / 3Ph / 50Hz
Cooling Operation	-15°C to 55°C
Heating Operation	-30°C to 30°C
Max Connected Indoor Units	64 units
Combination Ratio	50%-130% (up to 200% under specific conditions)
External Static Pressure	0-120Pa (adjustable)
